2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS

Product Categories

Shenzhen Greetwin Technology Co.,Limited

Contact Now

2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS

Name: 2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS
Brand: GREETWIN
Price: 65.70 USD

China 2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS wholesale

Brand Name : GREETWIN

Model Number : GW-23CP-V

Certification : SGS, ISO9001,CE,ROHS

Place of Origin : China

MOQ : 1pcs

Price : $65.70-$109.50/ PC

Payment Terms : T/T, L/C

Supply Ability : 5000pcs per Month

Delivery Time : 3 Working Days After Received Payment

Packaging Details : Carton with PE Foam

Product Name : 23dBm LTE800 Single Band Signal booster

Network : 3G, 2G, 4G

Weight : 1.2Kg

Gain : 75dB

Output Power : 23dBm

Dimensions : 182mm*118mm*18mm

Coverage : 2500sqm

Manual Gain Control : 12dB / 1dB Step

Contact Now

Product Description

Greetwin Repeater gsm signal booster 23dBm single band lte 800MHz mobile signal booster gsm

Frequency Range				Uplink	Downlink
CDMA 800MHz				824 - 849 MHz	869 - 894MHz
PCS 1900MHz				1850 - 1910MHz	1930 - 1990MHz
Gain				70dB±2dB	75dB±2dB
Output Power				20dBm±2dBm	23dBm±2dBm
Band width				Wide Band
Manual Gain Control				15dB
ALC				>25dB
Ripple in Band				8dB
Noise Figure				≤ 6dB
VSWR				≤ 2.0
Intermodulation Products				≤ -40dBc
Spurious Emission	9KHz~1GHz			≤ -36dBm
	1~12.75GHz			≤ -30dBm
Time Delay				≤ 1.5 μs
Frequency stability				≤ 0.01ppm
MTBF				> 50000 hours
Impedance				50 ohm
Power Supply				AC 90-264V,DC 6V/3A
Power LED				Power indicator
ISO(Alarm LED)		Red		Self oscillation or Strong input signal
		Green		Normal
Mechanical Specification
RF Connector			N-Female
Switch			Power Switch
Cooling			Heatsink Convection cooling
Humidity			< 90%
Operating Temperature			-20°C ~ +55°C
Environment Conditions			IP40
Installation Type			Wall Installation
Size			18211818mm
Weight			< 1.2 Kg

2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS

If you have a poor cellular signal, a cell phone signal booster is the answer. You are already paying a monthly fee for a service that either doesn't work or works sporadically. Cell phone boosters provide consistent, reliable cell service for one flat price.

Cell phone signal boosters are also called cell phone boosters, repeaters, signal amplifiers, and network extenders. They boost 4G LTE signals across all major North American carriers. A cell phone signal booster will end your dropped phone calls, unsent texts, and slow data speeds. You will never have a weak signal or dead zones again.

Application Diagram

Featrues:

1. Coverage up to 1000 m²
2. ALC Function
3. Simple in connection and installation
4. Optimal cooling with aluminum shell
5. Led indicators to show working status and ISO alarm.
Support any cellular devices (voice & data & video).

Installation:

The booster is fixed onto the wall through expansion bolts.
A. Drill holes in the targeted place and install expansion bolts.
B. Align the holes with the expansion bolts, place flat washers, spring washers, and nuts in turn, and tighten the nuts to fasten the installing support.
C. Place the booster on and fasten it.
D. Connect cables and power cables to the booster respectively.
E. After installing the booster as described above, power on the booster to check the operation status.

2500sqm GSM Cell Phone Signal Boosters IP40 75dB 1900MHz IP40 SGS Images
